Preliminary Steps
English
To install / to remove the belt clip
If necessary, attach the belt clip to the tranceiver,
making it slide along the fit runner placed on the rear
side of the battery (1) untill the lock will hook. To
remove the belt clip press the lock and slide the belt
clip away from the battery (2).
To install the external microphone (optional)
To install the external microphone, swing the protection cover of the external microphone/speaker jack.
This cover ensures the watertight integrity of the transceiver (spray-guard) that will not be ensured after
its removing. Insert the connector of the external microphone into the right jack.
In order to avoid mulfunction or damage to the transceiver, use only original microphones. Using non
original accessories will authomatically void the warranty.
Warning !
If an external earset-microphone is used, radio will not be splash proof.
