SEMICONDUCTOR LEAD ASSIGNMENT AND BLOCK DIAGRAM
A. DIODE
1. KDS113 : VHF TUNER BAND SWITCH APPLICATION
2. KDS114E : VHF TUNER BAND SWITCH APPLICATION
3. KDS120 : ULTRA HIGH SPEED SWITCHING APPLICATION
4. KDS121 : ULTRA HIGH SPEED SWITCHING APPLICATION
5. KDV154B : VHF,UHF TUNER AFC VCO FOR UHF BAND RADIO
