Technical Reference
47
Table 12. Component-side Connectors and Headers Shown in Figure 12
Label Description
A Front panel audio header
B PCI Express x1 add-in card connector
C PCI Express x1 add-in card connector
D Conventional PCI add-in card connector
E PCI Express 3.0 x16 add-in card connector
F PCI Express x1 add-in card connector
G PCI Express 3.0 x16 add-in card connector
H Rear chassis fan header
I Processor fan header
J 12 V processor core voltage connector (2 x 4 pin)
K Main power connector (2 x 12 pin)
L Front chassis fan header
M 3.0 Gb/s SATA connectors (black) and 6.0 Gb/s SATA connectors (blue)
N Front panel USB 2.0 header
O Front panel USB 2.0 header
P Front panel USB 2.0 header
Q Front panel USB 2.0 header
R Consumer IR emitter (output) header
S Alternate front panel power LED header
T Consumer IR receiver (input) header
U Front panel header
V Front panel IEEE 1394a header
W Chassis intrusion header
X Auxiliary fan header
