Intel
®
Desktop Board D101GGC Specification Update
5
SPECIFICATION CHANGES
The Specification Changes listed in this section apply to the Intel
®
Desktop Board D101GGC
Technical Product Specification (Order Number D36105). All Specification Changes will be
incorporated into a future version of that specification.
1. Change to Section 1.10.1 Fan Monitoring
Section 1.10.1 Fan Monitoring will change in its entirety as follows:
1.10.1 Fan Monitoring
Fan monitoring can be implemented using third-party software.
For information about Refer to
The functions of the fan connectors Section 1.11.2.2, page 27
2. The following note will be added to the Technical
Product Specification in Section 2.7.1 Back Panel
Connectors:
INTEGRATOR’S NOTES
Electrostatic discharge (ESD) can damage desktop board
components. Front-panel connectors should provide sufficient
protection to prevent ESD damage to components inside the
chassis enclosure.
3. Reference to support for second-generation SATA drives
is being removed. Section 3.3.2 PCI IDE Support will
change its entirety as follows:
3.3.2 PCI IDE Support
If you select Auto in the BIOS Setup program, the BIOS automatically sets
up the PCI IDE connector with independent I/O channel support. The IDE
interface supports hard drives up to ATA-66/100 and recognizes any ATAPI
compliant devices, including CD-ROM drives, tape drives, and Ultra DMA
drives. The interface also supports SATA drives. The BIOS determines the
capabilities of each drive and configures them to optimize capacity and
performance. To take advantage of the high capacities typically available
today, hard drives are automatically configured for Logical Block Addressing
(LBA) and to PIO Mode 3 or 4, depending on the capability of the drive. You
