Intel Desktop Board D201GLY Product Guide
12
Table 2. Desktop Boards D201GLY Components
Label Description
A PCI bus add-in card connector
B Hi-speed USB 2.0 headers
C Front panel audio header
D Back panel connectors
E Rear fan (3-pin) header
F 12 V processor core voltage connector (2 x 2)
G Main power connector (2 x 10)
H Processor
I DDR 2 DIMM connector
J IDE connector
K Front panel header
L Battery
M BIOS configuration jumper
