Intel Desktop Board D865GVHZ Product Guide
34
Connecting the Front Panel Header
Before connecting the front panel header, observe the precautions in “Before You Begin” on
page 21.
Figure 9-C on page 33 shows the location of the front panel header. Table 5 shows the pin
assignments for the front panel header.
Table 5. Front Panel Header
Pin Signal In/Out Description Pin Signal In/Out Description
Hard Drive Activity LED Power LED
1 HD_PWR Out Hard disk LED pull-
up (330
) to +5 V
2 HDR_BLNK_GRN Out Front panel green
LED
3 HDA# Out Hard disk active LED 4 HDR_BLNK_YEL Out Front panel yellow
LED
Reset Switch On/Off Switch
5 Ground Ground 6 SWITCH_ON# In Power switch
7 FP_RESET# In Reset switch 8 Ground Ground
9 +5 V Out Power 10 N/C Not connected
Connecting the USB 2.0 Header
Before connecting the USB 2.0 header, observe the precautions in “Before You Begin” on page 21.
Figure 9-D and E on page 33 shows the location of the USB 2.0 header. Table 6 shows the pin
assignments for the header.
Table 6. USB 2.0 Header
USB Port A USB Port B
Pin Signal Name Pin Signal Name
1 Power 2 Power
3 D- 4 D-
5 D+ 6 D+
7 Ground 8 Ground
9 Key (no pin) 10 Not connected
Note: USB ports may be assigned as needed.
