Intel Desktop Board D865GVHZ Product Guide
38
Add-In Card and Peripheral Interfac
e Con
nectors
Figure 11 shows
the PCI bus add-in card and p
eripheral interface conn
ectors for Desktop Board
D865GVHZ.
OM17028
D
E
F
B
C
A
Item
Description
A
PCI bus add-in card connector 3
B
PCI bus add-in card connector 2 (SMBus routed)
C
PCI
bus add-in card connector 1
D
F
loppy drive
E
Primary IDE
F
Secondary IDE
Figure 11. PCI Bu
s Add-in
Card and Periphe
ral Interface Connecto
rs
37
