Desktop Board D865PERL Specification Update
Table 43. DC Loading Characteristics
DC Current at:
Mode DC Power +3.3 V +5 V +12 V -12 V +5 VSB
Minimum loading 190.00 W 5.00 A 11.00 A 9.00 A 0.03 A 0.60 A
Maximum loading 310.00 W 11.00 A 15.00 A 15.00 A 0.10 A 1.38 A
4. Change to Thermal Considerations, Section 2.12
Section 2.12, Thermal Considerations will change in its entirety as follows:
2.12 Thermal Considerations
CAUTION
The use of an Intel
®
Pentium
®
4 processor operating above 2.80 GHz with this
Intel
®
desktop board requires the following:
• A chassis with appropriate airflow to ensure proper cooling of the
components on the board
• A processor fan heatsink that meets the thermal performance targets for
Pentium 4 processors operating above 2.80 GHz
The use of an Intel Pentium 4 processor with 1 MB of L2 cache on this Intel
desktop board requires the following:
• A chassis with a maximum internal ambient temperature of 38 Degrees
Celsius
• A processor heatsink that provides omnidirectional airflow so that air is
drawn across the processor voltage regulator area (item A in Figure 30).
Figure 29a illustrates an omnidirectional airflow heatsink.
