Intel Desktop Board D915GVWB Product Guide
34
Installing DIMMs
1. Observe the precautions in "Before You Begin" on page 23.
2. Turn off all peripheral devices connected to the computer. Turn off the computer and
disconnect the AC power cord.
3. Remove the computer’s cover and locate the DIMM sockets (see Figure 15).
OM17370
Channel A
Channel B
DIMM 1
DIMM 0
DIMM 1
DIMM 0
Figure 15. Installing a DIMM
