Standard Definition Configurations
D925XCV shown in diagram
Alternative motherboards and tested slots
D925XBC Slots 1 & 2 Slot 2 recommended,
D925XECV2 Slots 1,2,3 & 4 Slot 3 recommended with external controller card
D925XEBC2 Slots 1 & 2 Slot 2 recommended,
Supported Pixel formats and Resolutions Summary.
Overview
The Intel D925XCV motherboard with the combination of the Intel onboard 4 port SATA RAID
controller and four Maxtor Diamond Max 10 hard drives can support a range of file formats up to
10 bit RGB uncompressed.
Bluefish444 standard definition cards are only support with the motherboard.
The Bluefish444 SD cards has been tested in all PCI connectors for these motherboard types
3rd party Controllers
No 3rd party controllers where tested with the above motherboards, it is recommended that the 4
X PCI slot boards, D925XECV2 and D925XCV is selected when using the bluefish444 controller
card in conjunction with a 3rd part controller card
Resolution Supported Pixel formats onboard
10 bit RGB
(Cineon, DPX)
10 bit YUV
(QuickTime V210)
8 bit RGB
(TGA 32bit)
8 bit YUV
(AVI, WMV)
Pal Yes Yes Yes Yes
NTSC Yes Yes Yes Yes
SATA 0
SATA 1
SATA 2
SATA 3
System Drive
Media Drive
Software RAID 0
Striped
