Intel Desktop Board DCP847SKE Technical Product Specification
42
Table 12. PCI Express Full-Mini Card Connector (continued)
Pin
Signal Name
Additional Signal Name
39 +3.3 Vaux
40 GND
41 +3.3 Vaux
42 LED_WWAN#
43 Reserved
44 LED_WLAN#
45 Reserved (mSATA) Vendor
46 LED_WPAN#
47 Reserved (mSATA) Vendor
48 +1.5V
49 Reserved (mSATA) DA/DSS
50 GND
51 Reserved (mSATA) Presence Detection
52 +3.3V
Table 13. Dual-Port Front Panel USB 2.0 Header
Pin Signal Name Pin Signal Name
1 +5 V DC 2 +5 V DC
3 D− 4 D−
5 D+ 6 D+
7 Ground 8 Ground
9 KEY (no pin) 10 No Connect
2.2.2.2 Add-in Card Connectors
The board has the following add-in card connectors:
• One PCI Express Half-Mini Card
• One PCI Express Full-Mini Card
