Intel Desktop Board DH61SA Technical Product Specification
14
Table 2. Components Shown in Figure 1
Item/callout
from Figure 1 Description
A Conventional PCI bus add-in card connector
B Chassis intrusion header
C S/PDIF header
D PCI Express x1 add-in card connector
E Battery
F Back panel connectors
G Standby power indicator LED
H 12 V processor core voltage connector (2 X 2)
I Rear chassis fan header
J Piezoelectric speaker
K LGA1155 processor socket
L Processor fan header
M Low Pin Count (LPC) Debug header
N DIMM 1 (Channel A DIMM 1)
O DIMM 2 (Channel B DIMM 1)
P Trusted Platform Module (TPM) header
Q Main power connector (2 x 12)
R SATA connectors
S BIOS setup configuration jumper block
T Front panel header
U Intel H61 Express Chipset
V Serial port header
W Front panel USB 2.0 header
X Front panel audio header
