Intel Desktop Board DH61SA Technical Product Specification
20
1.7 Graphics Subsystem
The board supports system graphics through either Intel Graphics Technology or a
PCI Express 2.0 x1 add-in graphics card.
1.7.1 Integrated Graphics
The board supports integrated graphics through the Intel
®
Flexible Display Interface
(Intel
®
FDI) for processors with Intel Graphics Technology.
1.7.1.1 Analog Display (VGA)
The VGA port supports analog displays. The maximum supported resolution is 2048 x
1536 (QXGA) at a 75 Hz refresh rate. The VGA port is enabled for POST whenever a
monitor is attached, regardless of the DVI-D connector status.
1.8 USB
The board supports up to six USB 2.0 ports. The port arrangement is as follows:
• Four USB 2.0 ports are implemented with stacked back panel connectors (black)
• Two USB 2.0 front panel ports are implemented through one dual-port internal
header
All six USB ports are high-speed, full-speed, and low-speed capable.
NOTE
Computer systems that have an unshielded cable attached to a USB port may not
meet FCC Class B requirements, even if no device is attached to the cable. Use a
shielded cable that meets the requirements for full-speed devices.
For information about Refer to
The location of the USB connectors on the back panel Figure 9, page 40
The location of the front panel USB header Figure 10, page 41
