Intel Desktop Board DH67CF Technical Product Specification
14
Table 2 lists the components identified in Figure 1.
Table 2. Components Shown in Figure 1
Item/callout
from Figure 1 Descript
ion
A Back panel connectors
B Processor core power connector (2 x 2)
C Front panel USB 2.0 header
D BIOS Setup configuration jumper block
E SATA connectors
F Intel H67 Express Chipset
G Front panel USB 2.0 header
H Front panel USB 2.0 header
I Main power connector (2 x 12)
J Front panel header
K DIMM 1 (Channel A DIMM 1)
L DIMM 2 (Channel B DIMM 1)
M Alternate front panel power LED header
N Piezoelectric speaker
O Standby power LED
P Processor fan header
Q Consumer IR receiver (input) header
R S/PDIF out header
S LGA1155 processor socket
T Consumer IR emitter (output) header
U Low Pin Count (LPC) Debug header
V PCI Express x16 bus add-in card connector
W Chassis intrusion header
X System fan header
Y Front panel audio header
Z Battery
