Intel DH67CF User Manual

Intel Desktop Board DH67CF Technical Product Specification
46
Table 13 lists the component-side connectors and headers identified in Figure 10.
Table 13. Component-side Connectors and Headers Shown in Figure 10
Item/callout
from Figure 10 Descript
ion
A Processor core power connector (2 x 2)
B Front panel USB header
C SATA connectors
D Front panel USB header
E Front panel USB header
F Main power connector (2 X 12)
G Front panel header
H Alternate front panel power LED header
I Processor fan header
J Consumer IR receiver (input) header
K S/PDIF out header
L Consumer IR emitter (output) header
M LPC Debug header
N PCI Express x16 bus add-in card connector
O Chassis intrusion header
P System fan header
Q Front panel audio header
