Intel DP55WB - Media Series P55 micro-ATX Core i7 i5 LGA1156 Desktop Motherboard User Manual

Intel Desktop Board DP55WB Technical Product Specification
10
Table 1. Feature Summary (continued)
Expansion
Capabilities
• One PCI Express 2.0 x16 bus add-in card connector
• Two PCI Express 2.0 x1 bus add-in card connectors
• One PCI conventional bus connector
Hardware Monitor
Subsystem
• Hardware monitoring and fan control ASIC Heceta 6P
• Voltage sense to detect out of range power supply voltages
• Thermal sense to detect out of range thermal values
• Three fan headers using Heceta 6P fan speed control
• Three fan sense inputs used to monitor fan activity
• Fan speed control using voltage control (4-pin fan headers front, rear, and
processor) with selectable support in BIOS for 3 wire fans
• Support for Platform Environmental Control Interface (PECI)

Intel DP55WB - Media Series P55 micro-ATX Core i7 i5 LGA1156 Desktop Motherboard Specifications

General

Form Factor	Micro ATX
Socket	LGA 1156
Chipset	Intel P55
Memory Type	DDR3
Maximum Memory	16 GB
Storage Interfaces	6 x SATA 3Gb/s
Max LAN Speed	10/100/1000 Mbps
RAID Support	RAID 0, 1, 5, 10
Supported Processors	Intel Core i7 / Core i5
Memory Slots	4
Memory Standard	DDR3 1333/1066
Expansion Slots	1 x PCI Express 2.0 x16, 2 x PCI Express x1, 1 x PCI
USB Ports	12 x USB 2.0
Audio	Realtek ALC888S
