Intel Desktop Board DP55WB Technical Product Specification
12
Table 2 lists the components identified in Figure 1.
Table 2. Components Shown in Figure 1
Item/callout
from Figure 1 Description
A PCI Conventional bus add-in card connector
B Front panel audio header
C PCI Express x1 bus add-in card connector
D PCI Express x1 bus add-in card connector
E PCI Express x16 bus add-in card connector
F Back panel connectors
G Rear chassis fan header
H Processor fan header
I Processor core power connector (2 x 2)
J LGA1156 processor socket
K DIMM Channel A sockets (2)
L DIMM Channel B sockets (2)
M +5 V Standby Power Indicator LED
N Main power connector (2 x 12)
O Front panel header
P Front chassis fan header
Q Battery
R Alternate front panel power LED header
S BIOS Setup configuration jumper block
T Piezo Speaker
U SATA connectors
V Front panel USB headers (3)
W Intel P55 Express Chipset
X Chassis intrusion header
Y IEEE 1394a front panel header
Z S/PDIF out header

Intel DP55WB - Media Series P55 micro-ATX Core i7 i5 LGA1156 Desktop Motherboard Specifications

General

Form Factor	Micro ATX
Socket	LGA 1156
Chipset	Intel P55
Memory Type	DDR3
Maximum Memory	16 GB
Storage Interfaces	6 x SATA 3Gb/s
Max LAN Speed	10/100/1000 Mbps
RAID Support	RAID 0, 1, 5, 10
Supported Processors	Intel Core i7 / Core i5
Memory Slots	4
Memory Standard	DDR3 1333/1066
Expansion Slots	1 x PCI Express 2.0 x16, 2 x PCI Express x1, 1 x PCI
USB Ports	12 x USB 2.0
Audio	Realtek ALC888S
