Intel Desktop Board DP55WB Technical Product Specification
40
Table 10 lists the component-side connectors and headers identified in Figure 10.
Table 10. Component-side Connectors and Headers Shown in Figure 10
Item/callout
from Figure 10 Description
A PCI Conventional bus add-in card connector
B Front panel audio header
C PCI Express x1 bus add-in card connector
D PCI Express x1 bus add-in card connector
E PCI Express x16 bus add-in card connector
F Rear chassis fan header
G Processor fan header
H Processor core power connector (2 X 2)
I Main power connector (2 X 12)
J Front panel header
K Front chassis fan header
L Alternate front panel power LED header
M SATA connectors
N Front panel USB header
O Front panel USB header
P Front panel USB header
Q Chassis intrusion header
R IEEE 1394a front panel header
S S/PDIF out header
