Intel DZ68DB User Manual

Desktop Board Features
13
Table 2. Intel Desktop Board DZ68DB Components
Label Description
A Conventional PCI bus connector
B Conventional PCI bus connector
C Conventional PCI bus connector
D PCI Express 2.0 x1 add-in card connector
E IEEE 1394a header
F PCI Express 2.0 x1 add-in card connector
G PCI Express 2.0 x16 add-in card connector
H Back panel connectors
I 12 V processor core voltage connector (2 x 2 pin)
J Rear chassis fan header
K Processor socket
L Processor fan header
M DDR3 DIMM 3 socket
N DDR3 DIMM 1 socket
O DDR3 DIMM 4 socket
P DDR3 DIMM 2 socket
Q Front chassis fan header
R Chassis intrusion header
S Front panel CIR receiver (input) header
T Back panel CIR emitter (output) header
U Main power connector (2 x 12 pin)
V Battery
W Speaker
X SATA connectors
Y Alternate front panel power LED header
Z Front panel header
AA BIOS configuration jumper block
BB Standby power indicator LED
CC Front panel USB 2.0 headers
DD S/PDIF header
EE Front panel audio header
