Intel DZ68DB User Manual

9
1 Desktop Board Features
This chapter briefly describes the features of Intel
®
Desktop Board DZ68DB. Table 1
summarizes the major features of the Desktop Board.
Table 1. Feature Summary
Form Factor
ATX (243.84 millimeters [9.6 inches] x 294.64 millimeters
[11.6 inches])
Processor
• Intel
®
Core™ i7, Intel
®
Core™ i5, and Intel
®
Core™ i3 processors in
an LGA1155 socket:
― Integrated graphics processing (processors with Intel
®
HD
Graphics 2000 and 3000)
― External graphics interface controller
― Integrated memory controller
Chipset Intel
®
Z68 Express Chipset consisting of the Intel
®
Z68 Express
Platform Controller Hub (PCH)
Memory
• Four 240-pin DDR3 SDRAM Dual Inline Memory Module (DIMM)
sockets
• Dual Channel DDR3 1333 MHz and DDR3 1066 MHz support
• Support for 1 Gb, 2 Gb, and 4 Gb memory technology
• Support for up to 32 GB of system memory with four DIMMs using
4 Gb memory technology
• Support for non-ECC memory
• Support for 1.35 V low voltage JEDEC memory
Graphics
• Integrated graphics support for processors with Intel HD 2000 or
3000 Graphics:
― High-Definition Multi-media Interface* (HDMI*)
― DVI-I
― DisplayPort* interface
• Discrete graphics support for a PCI Express* 2.0 x16 add-in
graphics card
Audio
• 10-channel (7.1+2) Intel
®
High Definition Audio (Intel
®
HD Audio)
using a Realtek* ALC892 audio codec including:
― Front panel audio header with support for Intel HD Audio and
AC ’97 Audio
― Five analog audio jacks on the back panel
― Onboard S/PDIF out header and back panel optical S/PDIF out
connector
• 8-channel (7.1) Intel HD Audio via the HDMI interface
Expansion
Capabilities
One PCI Express 2.0 x16 add-in card connector
Two PCI Express 2.0 x1 add-in card connectors
Three Conventional PCI bus add-in card connectors
continued
