Advanced/RH Technical Product Specification •• Page 38
CELP 2.1 CONNECTOR (J1D1)
Signal Name Pin Pin Signal Name Signal Name Pin Pin
GND 1 41 D58 GND 81 121
TIO0 2 42 D56 TIO1 82 122
TIO2 3 43 GND TIO7 83 123
TIO6 4 44 D54 TIO5 84 124
TIO4 5 45 D52 TIO3 85 125
TIO8 6 46 D50 TI09 86 126
VCC3 7 47 D48 VCC5 87 127
TWE* 8 48 GND TIO10 88 128
CADS* 9 49 D46 CADV* 89 129
GND 10 50 D44 GND 90 130
CWE4* 11 51 D42 COE* 91 131
CWE6* 12 52 VCC3 CWE5* 92 132
CWE0* 13 53 D40 CWE7* 93 133
CWE2* 14 54 D38 CWE1* 94 134
VCC3 15 55 D36 VCC5 95 135
CCS* 16 56 GND CWE3* 96 136
GWE* 17 57 D34 CAB3 97 137
BWE* 18 58 D32 CALE 98 138
GND 19 59 D30 GND 99 139
A3 20 60 VCC3 RSVD 100 140
A7 21 61 D28 A4 101 141
A5 22 62 D26 A6 102 142
A11 23 63 D24 A8 103 143
A16 24 64 GND A10 104 144
VCC3 25 65 D22 VCC5 105 145
A18 26 66 D20 A17 106 146
GND 27 67 D18 GND 107 147
A12 28 68 VCC3 A9 108 148
A13 29 69 D16 A14 109 149
ADSP* 30 70 D14 A15 110 150
ECS1* 31 71 D12 RSVD 111 151
ECS2* 32 72 GND PD0 112 152
PD1 33 73 D10 PD2 113 153
PD3 34 74 D8 PD4 114 154
GND 35 75 D6 GND 115 155
CLK1 36 76 VCC3 CLK0 116 156
GND 37 77 D4 GND 117 157
D62 38 78 D2 D63 118 158
VCC3 39 79 D0 VCC5 119 159
D60 40 80 GND D61 120 160
To Next Page
