Intel NUC 11 Enthusiast User Manual

To install a different M.2 SSD:
1. Remove the small silver screw from the 110mm or 80mm metal standoff on the
board (A).
2. Remove the pre-installed SSD from the connector if there are any.
3. Make sure there is the metal standoff in the right position, depending on the
length of the SSD you are going to install
4. Align the space at the bottom of the new M.2 SSD to the key on the connector
(B).
5. Secure the card to the standoff with the small silver screw (C).

Intel NUC 11 Enthusiast Specifications

General

Dimensions	230 x 180 x 60 mm
Processor	Intel Core i7-1165G7
Graphics	Intel Iris Xe Graphics
Memory	Up to 64GB DDR4-3200
Storage	2x M.2 slots (NVMe SSD)
Networking	Intel Wi-Fi 6 AX201, Gigabit Ethernet
Ports	HDMI 2.0b, Mini DisplayPort 1.4
Power	230W Power Adapter
Operating System Support	Windows 10, Linux
