Intel® NUC 12 Pro Mini PC NUC12WSK
User Guide – August 2022
4.0 Changing the M.2 SSD
The Intel® NUC 12 Pro Mini PC NUC12WSK supports an 80mm and 42mm SSD.
Pre-installed M.2
Intel® NUC 12 Pro Mini PC NUC12WSKi3
500GB Gen 4 NVMe SSD
Intel® NUC 12 Pro Mini PC NUC12WSKi5
500GB Gen 4 NVMe SSD
Intel® NUC 12 Pro Mini PC NUC12WSKi7
500GB Gen 4 NVMe SSD
Find compatible M.2 SSDs in the Intel Product Compatibility Tool:
• Intel® NUC 12 Pro Mini PC NUC12WSKi3
• Intel® NUC 12 Pro Mini PC NUC12WSKi5
• Intel® NUC 12 Pro Mini PC NUC12WSKi7
To install a different M.2 SSD:
1. Remove the small silver screw from the 80mm or 42mm metal standoff on the
board (A).
2. Remove the pre-installed SSD/Intel Optane Memory from the connector.
3. Align the space at the bottom of the new M.2 SSD to the key on the connector.
4. Insert the bottom edge of the M.2 SSD into the connector (B).
5. Secure the card to the standoff with the small silver screw (C).

Intel NUC 12 Pro Specifications

General

Graphics	Intel Iris Xe Graphics
Dimensions	117 x 112 x 54 mm
Processor Options	12th Gen Intel Core i7/i5/i3 processors
Memory	Up to 64GB DDR4
Storage	M.2 SSD (PCIe NVMe or SATA)
Ports	HDMI 2.0
Networking	Intel Wi-Fi 6E AX211, Bluetooth 5.2
Operating System	Linux
Power Supply	90W or 120W adapter
Weight	0.7 kg
