8
Intel® NUC 12 Pro Mini PC NUC12WSK
User Guide – August 2022
3.0 Upgrade System Memory
The Intel® NUC 12 Pro Mini PC NUC12WSK has two 260-pin DDR4 SO-DIMM sockets.
Pre-installed memory
To upgrade memory, be sure to select memory modules that meet these
requirements:
• 1.2V low voltage memory
• 2133/2400/3200 MHz SO-DIMMs
• Non-ECC
Find compatible memory modules in the Intel Product Compatibility Tool:
• Intel® NUC 12 Pro Mini PC NUC12WSKi3
• Intel® NUC 12 Pro Mini PC NUC12WSKi5
• Intel® NUC 12 Pro Mini PC NUC12WSKi7
3.1 Upgrade to Different Memory
1. Observe the precautions in "Before You Begin" in Section 1.1.
2. Turn off all peripheral devices connected to the computer.
3. Turn off the computer and disconnect the power cord.
4. Remove the computer’s bottom chassis cover.
5. Remove the pre-installed memory module
a. Gently spread the retaining clips at each end of the memory socket, which
causes the module to pop out of the socket (C).
b. Holding the module by the edges, lift it away from the socket, and
store it in an anti-static package.
6. Install the new memory module
a. Align the small space at the bottom edge of the memory module
with the key in the socket.
b. Insert the bottom edge of the module at a 45 degree angle into
the socket (A).
c. When the module is inserted, push down on the outer edges of
To Next Page
