10
Intel® NUC 13 Pro Mini PC NUC13ANH
User Guide – March 2023
4.0 Changing the M.2 SSD
The Intel® NUC 13 Pro Mini PC NUC13ANH contains
• one 80mm connector supporting NVMe and
• one 42mm connector supporting SATA SSD
Pre-installed M.2
Find compatible M.2 SSDs in the Intel Product Compatibility Tool:
• Intel® NUC 13 Pro Mini PC NUC13ANHi7
• Intel® NUC 13 Pro Mini PC NUC13ANHi5
• Intel® NUC 13 Pro Mini PC NUC13ANHi3
To install a different M.2 SSD:
1. Remove the small silver screw from the 80mm or 42mm metal standoff on the
board (A).
2. Remove the pre-installed SSD from the connector.
3. Align the space at the bottom of the new M.2 SSD to the key on the connector.
4. Insert the bottom edge of the M.2 SSD into the connector (B).
5. Secure the card to the standoff with the small silver screw (C).
