8
Intel® NUC 13 Pro Mini PC NUC13ANH
User Guide – March 2023
3.0 Upgrade System Memory
The Intel® NUC 13 Pro Mini PC NUC13ANH has two 260-pin DDR4 SO-DIMM sockets.
Pre-installed memory
Intel® NUC 13 Pro Mini PC NUC13ANHi7
Intel® NUC 13 Pro Mini PC NUC13ANHi5
Intel® NUC 13 Pro Mini PC NUC13ANHi3
To upgrade memory, be sure to select memory modules that meet these
requirements:
• 1.2V low voltage memory
• 2400/2666/3200 MHz SO-DIMMs
• Non-ECC
• Up to 64GB of system memory supported with 2 SO-DIMMs using 32GB
memory modules
Find compatible memory modules in the Intel Product Compatibility Tool:
• Intel® NUC 13 Pro Mini PC NUC13ANHi7
• Intel® NUC 13 Pro Mini PC NUC13ANHi5
• Intel® NUC 13 Pro Mini PC NUC13ANHi3
If you plan to install only one memory module, install it in the lower
memory socket.
3.1 Upgrade to Different Memory
1. Observe the precautions in "Before You Begin" in Section 1.1.
2. Turn off all peripheral devices connected to the computer.
3. Turn off the computer and disconnect the power cord.
4. Remove the computer’s bottom chassis cover.
5. Remove the pre-installed memory module
a. Gently spread the retaining clips at each end of the memory socket, which
causes the module to pop out of the socket (C).
b. Holding the module by the edges, lift it away from the socket, and
store it in an anti-static package.
6. Install the new memory module
a. Align the small space at the bottom edge of the memory module
with the key in the socket.
b. Insert the bottom edge of the module at a 45-degree angle into
To Next Page
