NUC12DCM / NUC12EDB
User Guide – February 2022
3.0 System Memory
Intel® NUC 12 Pro X Kit NUC12DCMv9, NUC12DCMv7, and Intel® NUC 12 Extreme Kit
NUC12DCMi9, NUC12DCMi7 have two 260-pin DDR4 SO-DIMM sockets. Be sure to select
memory modules that meet these requirements:
• 1.2 V and 1.35 V (with XMP) low voltage JEDEC memory only
• DDR4 3200 MHz SO-DIMMs
• Max capacity - 64GB
• Non-ECC
• Note: 2 Gb memory technology (SDRAM Density) is not compatible
Find compatible memory modules in the Intel Product Compatibility Tool:
To install memory, follow these steps:
1. Observe the precautions in "Before You Begin" on page 5.
2. Turn off all peripheral devices connected to the computer. Turn off the computer
and disconnect the power cord.
3. Remove the computer’s side and top chassis covers as per the instructions in the
section 2.0 Open the chassis.
4. Align the small space (key) at the bottom edge of the memory module with the key
in the socket.
5. Insert the bottom edge of the module vertically into the socket (A).
6. When the module is inserted, push up the retaining clips until they snap into
place (B). Make sure the clips are firmly in place.
