Intel NUC7i5BNH User Manual

Intel NUC Kit NUC7i7BNH, NUC7i5BNH & NUC7i3BNH User Guide
8
2. Attach the two slightly larger black screws to the bottom chassis cover of the Intel NUC.
3. Slide the Intel NUC onto the VESA mount bracket.
Connect Power
Country-specific power plug attachments are included in the Intel NUC Kit box.
1. Choose the attachment for your region.
SKU
(Product
codes)
Attachments in the box
NUC7i7BNH
NUC7i7BNHR
NUC7i5BNH
NUC7i5BNHR
NUC7i3BNH
NUC7i3BNHR

Intel NUC7i5BNH Specifications

General

Processor	Intel Core i5-7260U
Graphics	Intel Iris Plus Graphics 640
Networking	Intel Gigabit Ethernet, Intel Wireless-AC 8265
Dimensions	115 x 111 x 51 mm
Processor Cores	2
Processor Threads	4
Processor Base Frequency	2.20 GHz
Processor Max Turbo Frequency	3.40 GHz
Memory Slots	2
Max Memory Size	32 GB
Graphics Base Frequency	300 MHz
Graphics Max Dynamic Frequency	1.05 GHz
HDMI	1x HDMI 2.0a
Memory	DDR4-2133
Storage	M.2 SSD and 2.5" HDD/SSD
Audio	7.1 digital audio via HDMI, Headphone/Microphone jack
Cache	4 MB
Memory Type	DDR4-2133
Storage Interface	SATA3 for 2.5" drive, PCIe x4 for M.2 SSD
Ethernet	Intel I219-V Gigabit LAN
USB Ports	4 x USB 3.0
Audio Jack	3.5mm headphone/microphone combo jack
Power Supply	65W power adapter
Operating System Support	Windows 10, Linux
Ports	4 x USB 3.0
Thunderbolt	1 x Thunderbolt 3 (USB Type-C)
