23
INSTALLING THE ANTENNA
Antenna Installation
Unpacking the Wooden Crate of t110W/t130W
The antenna pedestal is shipped completely assembled in its radome. Remove the
four shipping bolts which mount the antenna to the pallet. The pallet should be
lifted by means of a suitable sized lifting equipment.
Remove 20 clips from the edge of the wooden crate by using a at-head screwdriver and
detach the top panel and side panels.
Tips: Using a at-head screwdriver, remove the clips as shown in the picture.
To Next Page
