12
System Components
Antenna unit
Antenna Unit
The antenna of Intellian v240C is composed with the following components for the
optimum search and reception of satellite signal.
• Mechanical Unit – manipulates the antenna to receive the optimal satellite signal
regardless of the movement of the vessel.
• Control Unit – controls mechanical operation of the antenna.
• RF Unit – transmits the optimum satellite signal to the receiver.
• Radome – protects the antenna from the severe marine environment.
