Intellian v240C User Manual

143
Aptus
®
WEB
WARNING: Tick the checkbox before modifying the settings. After conguration, click
'set...' button to submit the settings.
5
Elevation Adjust
Adjust the elevation to offset the angle difference
between the mechanical elevation angle and actual
elevation angle.
6
Conical Range
The relative force of the motors controlling azimuth
and elevation. Set the conical range while the an-
tenna is in tracking MENU.
7
Idle MENU
Release the elevation and cross level motor brakes
while the antenna is in SETUP MENU. The antenna
can be moved manually during the MENU.
8
Reboot Reboot the system.
9
Search & Tracking
Parameter Setting
DVB Detect and Tracking Level Threshold: display /
set current detect level threshold and tracking level
threshold when DVB tracking MENU is chosen to be
used.
- NBD Detect and Tracking Level Threshold: display
/ set current detect level threshold and tracking level
threshold
when NBD tracking MENU is chosen to be used.
- TX Enable Threshold: display / set TX enable
threshold. - Wait time: set the time-out for automat-
ic initiation of a search after the signal level drops
below the pre-dened threshold value.
- Search Step: set increment step size.
- Search 1 & 3 Range: set Search 1 & 3 search
range. Search is conducted in a two-axis pattern
consisting of alternate movements in azimuth and
elevation as forming expanding square.
- Search 2 Range: is reserved for future use.
10
Tilt Sensor Bias
Adjust the two solid-state tilt sensors used to
provide absolute cross-level tilt of the antenna and
elevation feedback to eliminate long-term point-
ing drift (error). Tilt bias is required to be adjusted
when the antenna control board or sensor box is
replaced. Check to see whether or not the bubble is
located at the center of the level vial.
11
Rate Sensor Adjust
Calibrate DC voltage output from the three rate
sensors used to sense antenna motion in azimuth,
elevation and cross-level axes. During the calibra-
tion process, the antenna should avoid any motion
as it can affect the antenna’s performance.
