Intellian v240C User Manual

25
INSTALLING THE ANTENNA
After complete removal
of the wooden bar in
section A directly above,
the packaging should be
seen as shown left.
Now prepare to remove
the Base frame by
removing bolts from
wooden crate oor and
base frame legs.
B.
C.
4. Removal of Radome Panel Supports and Base Frame
Remove the wooden bar
that supported radome
panels using an Impact
Drill.
A.
