Intellian v240C User Manual

v240C – Marine Satellite Communication System
30
7. Dismantle the Antenna Package and Free the CL Arm
Dismantle the wooden
assembly of the antenna
package using an impact
drill.
Remove the vinyl layer
from the antenna.
Under the wooden
support, there is a post
laying. Remove the post
by sliding it out, then cut
the ties or tapes around
the post.
A.
B.
C.
