Intellian v240C User Manual

73
OPERATING THE ACU
6. Set MODEM TYPE * and LNB LOCAL.
MODEM TYPE is to select a proper data communication port on the ACU to interface with
the satellite Modem.
Set Modem type
and LNB local frequency
GYRO TYPE* (V240)
• NO DEVICE
• NMEA
• NMEA 2000
• GROUND TEST
Gyro search Mode
Setting of Heading Device
Existence of Heading Data No
Device
NMEA
NMEA 2000
Ground Test
With Heading Data
Search 1 Search 3 Search 3
Without Heading Data
Search 1 Search 1 Search 3
MODEM TYPE LOCAL FREQ.
IDIRECT-I/O 0 5150MHz
LOADING ...
DO NOT TURN OFF !
8. Setting is being loaded to the system.
The ACU will restart the system automatically after uploading the setting.
DO NOT TURN OFF ACU POWER while data is being uploaded.
Loading settings
LOAD ?
YES NO
7. Press BACK key to load the current setting or abort and return to the main display.
Load
MODEM TYPE*
• USER SETTING
• IDIRECT-I/O
• IDIRECT-AMIP
• COMTECH-I/O
• COMTECH-ROSS
• HUGHES
• SATLINK-SERIAL
• SATLINK-VACP
• ELEKTRIKOM-AMIP
• GILAT-SERIAL
• IPSTAR-SOTM
TRACKING 125.0E ASIA6AH SIG:201
AZ:183.7( 183.7) EL: 47.3 SK: 03.0 Fn
9. Antenna has locked onto the target satellite.
Tracking status
