v240C – Marine Satellite Communication System
84
Diagnossis Procedures
Refer to the diagnostic codes for the test results.
Single diagnostic
test result
Full diagnostic
test result
Diagnostic Menu
Antenna Menu
Setup Mode
SETUP MODE ?
YES NO
1. Press LEFT arrow key to move cursor to YES and press OK key to enter SETUP mode.
+ANTENNA +SATELLITE
+SYSTEM +INSTALLATION
2. Press OK key to enter ANTENNA menu.
+BLOCK ZONE +DIAGNOSTIC
3. Press arrow keys to move cursor to DIAGNOSTIC menu and press OK key to enter it.
DIAGNOSTIC COMMUNICATION
FULL TEST READY
4. Press UP and DOWN arrow keys to select a full diagnostic test or single diagnostic test
and press OK key to execute the selected diagnostic test.
Menus for diagnostic are FULL TEST and CODE 101 ~ CODE 116.
DIAGNOSTIC FULL TESTING
FULL TEST
- -
5. A full diagnostic is successfully completed.
DIAGNOSTIC COMMUNICATION
CODE 101 RESULT : PASSED
6. A single diagnostic test is successfully completed.
