• Open Network Video Interface Forum (ONVIF) V 2.2
General
• 32-bit ARM9 RISC CPU
• 8 MByte flash memory
• 64 MByte SDRAM
• Supported image resolutions: 1280 x 800, 1280 x 720 (720p HDTV) , 640 x 480 (VGA),
320 x 240 (QVGA)
• Supported video compression formats:
- Motion-JPEG
- MPEG4 Part2 (ISO/IEC 14496-2), Profile: SP
- H.264-BP
- 3GPP
• Video frame rate up to 30 fps at 1280 x 800
• Uni- and Multicast
• 1 x analog video out BNC connector
• Protocols supported: TCP/IP, DHCP, PPPoE, ARP, ICMP, FTP, SMTP, DNS, NTP,
UPnP, RTSP, RTP, HTTP, TCP, UDP, 3GPP/ISMA RTSP, Bonjour, ONVIF 2.2
• Certifications: FCC Class B, RoHS, CE
Network
• LAN connector: RJ45 port to connect to 10/100 Mbps Ethernet
Image Sensor and Lens
• 1/4" Micron Progressive Scan CMOS sensor
• 1.0 megapixel resolution (1,280 H x 720 V)
• S/N ratio: 39 dB (max.)
• Pixel size: 3 µm x 3 µm
• Manual brightness, contrast, saturation, hue control
• Minimum illumination: 0 lux with IR LEDs on
• 3 x high-performance IR LEDs, effective range 15 m (50 ft.)
• IR wavelength: 850 nm
• Mechanical IR cut filter with 3 settings: On, Off and Auto (with adjustable threshold)
• Focal length 4.0 mm, horizontal field of view 53?
• Maximum relative aperture F1.8
Users and Security
• 10 user accounts
• 3 different access levels: administrator, operator and viewer
• Password-protected access to the video streams, or access without password
• HTTPS (SSL v3)
Power
• External power adapter: 12 V DC, 1.0 A
• Built-in IEEE 802.3af PoE (Power over Ethernet)
• Power consumption:
- 3.3 W without IR
- 7 W with IR on
For more information on Intellinet products, consult your local dealer or visit www.intelllinet-network.com.
All names of products or services mentioned herein are trademarks or registered trademarks of their respective owners. Distribution and
reproduction of this document, and use and disclosure of the contents herein, are prohibited unless specifically authorized.
