Standards
• IEEE 802.3 (10Base-T Ethernet)
• IEEE 802.3u (100Base-TX Fast Ethernet)
• IEEE 802.3af (Power over Ethernet 802.3at Type 1)
• Open Network Video Interface Forum (ONVIF) V 2.2
General
• FA626TE ARM9 V5TE CPU
• 16 MByte flash memory
• 128 MByte SDRAM
• Supported image resolutions: 1920 x 1080 (1080p HDTV) ,1280 x 720 (720p HDTV) ,
640 x 480 (VGA), 320 x 240 (QVGA) and 160 x 120
• Supported video compression formats:
- Motion-JPEG
- MPEG4 Part2 (ISO/IEC 14496-2), Profile: SP
- H.264-BP
- 3GPP
• Uni- and Multicast
• 1 x alarm input
• 1 x alarm output
• Protocols supported: TCP/IP, DHCP, PPPoE, ARP, ICMP, FTP, SMTP, DNS, NTP,
UPnP, RTSP, RTP, HTTP, TCP, UDP, 3GPP / ISMA / RTSP, Bonjour, ONVIF 1.02
• Certifications: FCC Class B, RoHS, CE
Connectors
• LAN connector: RJ45 port to connect to 10/100 Mbps Ethernet
• DC power jack
• Terminal block for 1 alarm input and 1 output
• 1 x analog video out RCA connector
• MicroSD memory card slot
• Hardware reset button
Image Sensor
• 1/2.7” Progressive Scan CMOS sensor
• 2.0 megapixel resolution (1,920 H x 1080 V)
• S/N ratio: 39 dB (max.)
• Pixel size: 3 µm x 3 µm
• Manual brightness, contrast, saturation, sharpness, exposure
• Shutter: 1/2 - 1/10000 sec.
Lens
• Varifocal megapixel lens
• DC-controlled auto-iris
• Focal length 3.3 mm - 12 mm
• Angle of view: 31.0° - 95.0° horizontal
• Maximum relative aperture: F1.2
IR Night-Mode
For more information on Intellinet products, consult your local dealer or visit www.intelllinet-network.com.
All names of products or services mentioned herein are trademarks or registered trademarks of their respective owners. Distribution and
reproduction of this document, and use and disclosure of the contents herein, are prohibited unless specifically authorized.
