- 12 -
Rear
Power Connector: The connection for the power adapter, which is
supplied with the camera.
Reset Switch: If you need to perform a hardware reset, you can
insert a paper clip into the reset hole and depress the
switch for 10 seconds.
Speaker: Stereo connector for the connection of active speakers
or other line-out audio sources.
LAN: Connection for standard RJ45 Cat5 (or better) network
cable. Maximum length is 100 m / 300 ft.
Connection of NSC15 to the network (wired)
