53‐01130‐200RevA06/09/20

Page2

INSTALLATIONGUIDE



ApplicationConnections:



Signal Function ConnectionType

SwitchInput(GND) Userinputallowstheabilitytotoggleprimarydisconnectstate 0.25”QuickConnectFemale

AlarmOutput(VBAT) 350mAoutputindicatingdisconnectstateandlowvoltagecondition 0.25”QuickConnectFemale

Ground GroundsupplyforBatteryGuard1000 0.25”QuickConnectFemale

RV‐CNetwork RV‐Ccommunicationswithconstantbattery 4pinMolexMini‐Fit

SwitchedRV‐C RV‐Ccommunicationswithswitchpower 4pinMolexMini‐Fit

BatteryPositive BatteryPowerforPrimaryandAuxiliaryLoads 5/16”RingTerm

PrimaryLoad 100AmpDisconnectforPrimaryLoads 5/16”RingTerm

AuxiliaryOutput 2AmpDisconnectforAuxiliaryLoad 0.25”QuickConnectFemale



RV‐CConnectors:

TheRV‐Cnetworkconnectionsuse4pinMini‐FitconnectorsandfollowstheRV‐Cstandardpin‐outconvention

describedinsection“2.1.4Connectors”oftheRV‐Cguideline.

PinNumber Description

1 CANH

2 CANL

3 SwitchedPS‐

4 SwitchedPS+



PinNumber Description

1 CANH

2 CANL

3 PS‐

4 PS+
