Inteno FG101 Installation Guide

54
English Svenska Suomi Norsk
FG101
Fiber Residential Gateway
FG101
AR382
AR382
FG101
Start Box
Check that the following items
are in the Start Box:
• IntenoFG101FiberResidential
 Gateway
• Poweradapter
• LANNetworkcable(yellow)
• WANNetworkcable(grey)
• Telephonecable
• AntennaforWLAN(wirelessdata
 connection)
Connecting the WAN
TheWANconnectionontheFG101isa
berportonthebottomofthemodem.
1.Removetheplasticcoverwhichis
 mountedonthebottomofthemodem.
2.Themodemshouldbemountedtothe
 bercontactonthewall.
3.Removethecoveronthebracketby
 movingittotheright.
4.Aberconnectionismountedinthe
 bracket.Removetheplasticcovering
 fromthecontact.
5.Thebracketandthemodemhave
 three(3)longitudinalmountingguides
 toalloweasymountingofthemodem
 tothebracket.
6.Matchthemodem’smountingguides
 tothebracketandpullthemodemto
 theleft.
7.Themodemisnowconnected.Ifyou
 intendtousetheWLANconnection,
 makesureyouattachtheincluded
 antenna.
Connecting the LAN
1.Shutdownyourcomputer.
2.Connecttheyellownetworkcable
 betweentheFG101networkport
 (LAN1-4)andthenetworkportonthe
 backorsideofyourcomputer.
 NOTE!Insomecases,yourbroadband
 serviceproviderwillinstructyouto
 connecttoaspecicnetworkport
 (LAN1-4).Verifythisinthedocuments
 and/ormanualyoureceivedfromyour
 serviceprovider.
Back
Front
FG101
FiberResidentialGateway
FG101
FiberResidentialGateway
ThisinstallationguidewillhelpyouinstalltheIntenoFG101,Fiber
ResidentialGateway.Yourserviceproviderwillsupplyyouwith
informationaboutloginandaccess
a
b
c
d
Note!Thisproductcontainsalasertransmitter.Lasercan
beharmfultoyoureyes.Therefore,theproductmustbe
handledaccordingtotheinstructions.Onlyuse(mode”on”)
FG101whenitisinstalledinthebottomplate.

Inteno FG101 Specifications

General

Brand	Inteno
Model	FG101
Category	Switch
Language	English
