12 MODEL, SPECIFICATION & PARAMETERS
In case any parameters in the following table are changed, no other notice will be given. The parameters specified on the nameplate shall prevail.
NOTE
The cooling capacity of the air conditioner is measured in a standard environment where the indoor dry/wet bulb temperature is 27°C/19°C
and the outdoor dry/wet bulb temperature is 35°C/24°C; the heating capacity is measured in a standard environment where the indoor
dry/wet bulb temperature is 20°C/15°C and the outdoor dry/wet bulb temperature is 7°C/6°C; and the actual cooling/heating capacity
changes with the rise/fall of the indoor/outdoor environment temperature and relative humidity.
The noise of the unit is measured in the semi noise suppression lab according to the national standards, and the accuracy extent is
±4dB(A).
During the actual service, the noise will be changed according by ducts, and the practical noise value is about 45dB(A) or lower.(after be
installed the mute device.)
External static pressure range of the air conditioner under experiment is 0 Pa.
Model
220V 3
Ph~ 60Hz
208-230V 3
Ph~ 60Hz
1391x1139x721
1255x700x908
Power supply
(V/Hz)
Circulating air flow (m
3
/h)
(wide×high×deep)
Dimension
(mm)
Weight(kg)
Hot fuse specification
IDCE090KF-5
9.0
____
26.1
____
6.6
1.6
5100/62pa
56
67
170
187
199
T5A250VAC;15A250VAC
IDCE120KF-5
12.1
34.4
____
7.8
1.8
6800/75pa
60
70
170
Standard cooling capacity (KW)
Standard heating capacity (KW)
Rated input power（kW）
Rated input current（A）
Noise dB(A)
Indoor unit
Indoor unit
Indoor unit
Indoor unit
Outdoor unit
Outdoor unit
Outdoor unit
Outdoor unit
Control method
Remote control or wired control or centralized control
Note: 1. Cooling capacity test condition: indoor dry bulb /wet bulb temp: 27°C/19°C; outdoor dry bulb/wet bulb temp:35 C/24 C.
Heating capacity test condition : indoor dry bulb/wet bulb temp:20°C/15°C; outdoor dry bulb/wet bulb temp: 7°C/6°C.
The actual cooling and heating capacity is proportional to the value of ambient temp and relative humidity.
2. Noise level is tested in half-anechoic room.
3. In actual situation, the outlet noise level will change according to different duct. The actual noise level is about
45dB(A) or smaller.
35.0
____
26.0
____
Cooling
Heating
Cooling
Heating
Standard
power (kW)
Standard
current (A)
____
