8. PRE AMP OUTPUT CONNECTOR
The line out signal of this unit can be used for connecting to another amplifier, e.g. recorder or signal
processor etc.
9. SPEAKER TERMINAL
These terminals are for the connection to speakers. Select the 4Ω terminals or the high impedance terminals.
Do not select both low and high impedance terminals else overload may occur.
10. IMPEDANCE SELECTOR
This switch is for selecting the required high impedance at the speaker terminals.
* WARNING: For low impedance output (4ohm), remove the jumper from the option terminals. For high
impedance output (70V, 100V) install the jumper. Do not use both the low and high
impedance outputs at the same time, doing so could damage your amplifier and invalidate the
warranty.
Voltage/Impedance
MODEL
ACR-120M
100V
70V
25V
4Ω
83Ω
41Ω
5.2Ω
4Ω /21.9V
