CN-9102 Dual Channel Compressor/Limiter with Gate
Specifications
Audio Input
Type Electronic balanced input
Impedance 47kΩ
Nominal Operating Level +4dBv/-10dBu, switchable
Maximum Input Level +20dBu balanced/unbalanced @+4dBv
Side Chain
Type Unbalanced Tip=return, Ring=send
Impedance >22kΩ, <150Ω
Maximum Input/Output Level +20dBu
Audio Output
Type Electronic balanced output
Impedance <75kΩ, balanced/unbalanced
Maximum Input Level +21dBm
THD < 0.1%
Noise & Hum @ Unity Gain > -94dBu
Crosstalk > -85dBu
Frequency Response 5Hz – 50kHz
Gate Section
Threshold Variable (-60dB to –10dB)
Rate Variable (20msec to 2sec)
Compressor Section
Type Hard and soft knee, switchable
Threshold Variable (-40dB to +20dB)
Ratio Variable (1:1 to
:1)
Attack Variable (0.1msec to 200msec)
Release Variable (50msec to 3sec)
Output Variable (-20dB to +20dB)
Indicators
12-LED Gain Reduction Meter -30-25-20/-15/-12/-9/-6/-5/-4/-3/-2/-1
12-LED Input/Output Level Meter -30/-25/-20/-15/-10/-6/-4/-2/0/+2/+4/+6
Fuse 160mA (120VAC), 80mA (220VAC)
GENERAL
Power Source 100 –240VAC, 50/60Hz
Power Consumption 19W
Weight 3.5 Kg (7.7 lbs)
Dimensions 482(W) x 44(H) x 280(D) mm
19(W) x 1.75(H) x 11(D) in.
Specifications and design subject to change without notice for improvements.
