Inter-m EQ-2131 Service Manual

1
Specifications
1
Electrical Parts List
2, 3, 4, 5, 6
Top and Bottom View of P.C. Board
7, 8, 9, 10
Wiring Diagram 11, 12, 13
Block Diagram 14, 15, 16
Schematic Diagram 17 ~ 26
Exploded View of Cabinet & Chassis / Mechanical Parts List 27 ~ 32
Ass’y Drawing 33 ~ 38
CONTENTS
SPECIFICATIONS
ELECTRICAL
• Output Level / Impedance ....................................................................................................0dB/600Ω, BAL
• Input Sensitivity / Impedance................................................................................................0dB/600Ω, BAL
• Total Harmonic Distortion ...................................................................................................Less than 0.01%
• Frequency Response....................................................................................................20Hz~20kHz (±1dB)
• Signal to Noise Ratio..........................................................................................................Better than 85dB
• Equalizer Level .....................................................................................................................................+6dB
• Equalizer Frequency
EQ-2131/2231 ...........................................1/3 Octave ISO (International-Standard-Organization) centers
EQ-2215.................................................................................................................2/3 Octave ISO centers
• High Pass Filter...................................................................................................................80Hz (18dB/oct)
• Cut Only Mode..............................................................................................................-12dB or -24dB±3dB
GENERAL
• Power Source ..................................................................................... AC 100V/120V/230V/240V, 50/60Hz
• Power Consumption .................................................................................................... EQ-2131/2215: 15W
.............................................................................................................................................. EQ-2231: 20W
• Weight ............................................................................................................. EQ-2131/2215: 4.5kg/10Lbs
..................................................................................................................................... EQ-2231: 5kg/11Lbs
• Dimensions.................................................................. 482mm/19in(W)
88mm/3.5in(H) 280mm/11in(D)
* Due to continuous improvements specifications and design are subject to change without prior notice.

Inter-m EQ-2131 Specifications

General

Brand	Inter-m
Model	EQ-2131
Category	Stereo Equalizer
Language	English
