TOP AND BOTTOM VIEW OF P.C BOARD
6
Ref No. Part No. ValueDescription
EQ-2131/2231/2215 4448997310 AC INLET PA-9200RC AC INLET
4648097210 JW-S11RKKR ROCKERS RED POWER SW
4355891914 CON ASS’Y 2P MX-200 ASS’Y 2P
4355470614 CON ASS’Y 2P(300MM) ASS’Y 2P
4355917701 SOCKET TERMINAL (YEL-GRE/80MM) GND
4355864109 SOCKET TERMINAL(190M/M.BK) INLET-250T
4355864209 SOCKET TERMINAL(190M/M.WH) INLET-250T
4308993510 AC CORD KKP-210/KKS-16T (JIS) 100V (J)
4308999310 AC CORD UL 3 (INLET) 120V (E)
4308997310 AC CORD DOME 3-CORES 220V (DOM)
4308999410 AC CORD V+VII6A-250VHOVV-F3G 230V (R)
4308991010 AC POWER CORD 10A/250V UK 230V~240V (C)
4308998000 AC CORD POWER FOR SAA 240V (D)
EQ-2131 4355773021 CON ASS’Y 6P (510MM) ASS’Y 6P
4355885510 CON ASS’Y 7P(RED/450MM) ASS’Y 7P
2828063410 POWER TRANS 100V E-30IJ/31IJ 100V
2828063400 POWER TRANS 115/230V E-30/31I 120V ~ 240V
5508411134 FUSE 218T 20MM 200MA/250V UCSK 100V ~ 120V
5508410734 FUSE 50T 20MM 100MA/250V S/V 220V ~ 240V
EQ-2231 4355773014 CON ASS’Y 6P (300MM) ASS’Y 6P
4355773019 CON ASS’Y 6P (450MM) ASS’Y 6P
4355876610 CON ASS’Y 7P(BLACK/360MM) ASS’Y 7P
4355885510 CON ASS’Y 7P(RED/450MM) ASS’Y 7P
2828083620 TRANS POWER E62 100V ~ 240V
5508411934 FUSE 218T 20MM 630MA/250V UCSK 100V ~ 120V
5508411434 FUSE TS 20MM 315MA/250V U/C/S 220V ~ 240V
EQ-2215 4355773014 CON ASS’Y 6P (300MM) ASS’Y 6P
4355773019 CON ASS’Y 6P (450MM) ASS’Y 6P
4355885510 CON ASS’Y 7P(RED/450MM) ASS’Y 7P
4355876610 CON ASS’Y 7P(BLACK/360MM) ASS’Y 7P
2828063400 POWER TRANS 115/230V E-30/31I 100V ~ 240V
5508411134 FUSE 218T 20MM 200MA/250V UCSK 100V ~ 120V
5508410734 FUSE 50T 20MM 100MA/250V S/V 220V ~ 240V
ASS’Y
EQ-2131/EQ-2231/EQ-2215
