Inter-m EQ-2131 User Manual

8
EQ-2131/2231/2215
GRAPHIC EQUALIZER
1. BALANCED XLR INPUT CONNECTORS
One balanced 3-pin female XLR input connector is provided for each channel. This connector is wired in
Parallel to the corresponding balanced 1/4” TRS input connector.
2. BALANCED 1/4” TRS INPUT CONNECTORS
One balanced female 1/4” TRS input connector is provided for each channel. This connector is wired in
Parallel to the corresponding balanced XLR input connector.
3. BALANCED XLR OUTPUT CONNECTORS
One balanced 3-pin male XLR output connector is provided for each channel. This connector is wired in
Parallel to the corresponding balanced 1/4” TRS output connector.
4. BALANCED 1/4” TRS OUTPUT CONNECTORS
One balanced female 1/4” TRS output connector is provided for each channel. This connector is wired in
Parallel to the corresponding balanced XLR output connector.
5. AC INPUT
Connect this product to an appropriate AC power source using the supplied Universal AC Power Cord.
215.9*279.4_EQ-2131/2231/2215_E 2004.10.18 2:47 PM 페이지11

Inter-m EQ-2131 Specifications

General

Brand	Inter-m
Model	EQ-2131
Category	Stereo Equalizer
Language	English
