EQ-2131/2231/2215
GRAPHIC EQUALIZER
Unpacking
Please take a few minutes to read this manual to familiarize yourself with important information regarding
installation, product features, and operation.
As with most electronic devices, ORIGINAL PACKAGING (OR EQUAL) IS REQUIRED in the unlikely event that
the product needs to be returned for servicing.
Short Form Instructions
1. Prior to connecting the AC power, adjust the LEVEL slider control to the fully attenuated position (all the
way down).
2. All other sliders should be set to the “0” or center position.
3. The BYPASS switch should be in the OFF position.
4. Connect an appropriate line level input signal to either the balanced XLR or the balanced 1/4” TRS (Tip-
Ring-Sleeve) connector marked INPUTS.
5. Connect the OUTPUTS using either the balanced XLR or the balanced 1/4” TRS connector to an
appropriate device.
6. With the power switch in the OFF position, plug in the supplied Universal AC power cord to the product
and an appropriate AC source.
7. Depress the power switch to the ON position. An LED within the power switch will illuminate.
8. The product is ready for operation. Slowly increase the LEVEL slider to the desired operating level without
exceeding “0”, then make other adjustments as necessary.
9. Operate the product and the system in a manner which DOES NOT illuminate the PEAK warning indicator.
