EQ-2131/2231/2215
GRAPHIC EQUALIZER
Input
Connect an appropriate line level input signal to either the balanced XLR or the balanced 1/4” TRS connector
marked INPUTS. Common and standard rules of interconnect apply, including limiting the number of inputs to
one per channel. Knowledge of the input signal is required and should be Balanced Low Impedance 1KOhm
+4dBu.
Output
Connect the OUTPUTS using either the balanced XLR or the balanced 1/4” TRS connector to an appropriate
device. Common and standard rules of interconnect apply, including the ability to split output signals.
Knowledge of the input requirements of the receiving device is required and should be Balanced +4dBu and at
least 10kOhms.
