14
IP-1015WS(NETWORK WALL SPEAKER)
3-1
3-1
Concrete screw standard
STANDARD
50 mm 8 mm
Drill bit diameter_M (mm)
50 mm 13 mm 45 mm
The product manufacturer is not responsible for any accident to damage occurring from using screws that do not meet the
aforementioned standard specifications.
Anchor length_L (mm) Hexagon head_b (mm) Insertion depth_h (mm)
