Inter-m IP-1015WS - Specification

10
IP-1015WS(NETWORK WALL SPEAKER)
Specification
IP-1015WS
TYPE 2Way 5” Network Wall Speaker
Driver
LF 5", V/C : 25.4mm / 8
HF 0.5", V/C : 13.4mm / 8
Maximum SPL [Cont]
96dB
(PoE 802.3af)
99dB
(PoE+ 802.3at)
Frequency Range 120Hz~20kHz
Nominal
Dispersion
(HxV)
1kHz 180° X 120°
4kHz 120° X 70°
Enclosure Type : Bass-reflex/Material : ABS
Amplifier
Rated output power
(8,1kHz sine wave)
3.7W
(PoE 802.3af)
10W
(PoE+ 802.3at)
Mic
Embedded mic
50Hz ~ 16kHz
Line output
Maximum audio output +6dBV ± 3dB
Frequency response 20Hz - 20kHz (+1/-3dB)
THD+N
(20Hz HPF, AES17 LPF)
Less than 0.1%
S/N(20Hz HPF,
AES17 LPF, A-WTD)
Better than 91dB
